TECO Micro VFD, 230 Three Phase Input, 0-240 Three Phase Output, 10.5 Amps, 3 HP, L510-203-H3-U

Special Price $684.00 was $720.00
TECO Westinghouse L510-203-H3-U, 230/60 3P VAC Input

0-240 VAC, 3 Phase Output and 3 HP
TECO Westinghouse Micro Variable Frequency 3 HP Sensorless Vector AC Drive L510-203-H3-U is a 230 VAC Three Phase input and a 0-240 VAC three phase output VFD. The TECO L510 Micro VFD is 3 HP, 10.5 Constant torque amps, 4 KVA and 2.2 KW. The Unit's speed range is .01-650.00 Hz. The L510 drive can be set with the onboard keypad with up and down arrows or with the onboard potentiometer.

The TECO L510 Micro Drive has external input termninas for AVI (0/2-10V), and ACI (0/4-20mA) input. The main features are overload detection, 8 preset speeds, Auto-run, Acc/Dec Switch, Main/ Alt Run Command Select, Main/ Alt Frequency Command Select, PID Control, Torque Boost, V/F Start Frequency and Fault Reset.

Chassis Style Enclosure (IP20) with DIN Rail Option

UL Approved, cUL Listed and CE Marked.

TECO Westinghouse VFD model is L510-203-H3-U.

Brand TECO
MFR Part Number L510-203-H3-U
Old MFR Part Number L520301H3U
MPN Alternate L510-203-H3-N
Type VFD
Cross Reference Part Number JNEV-203-H3
Application Industrial Automation
Exact Amperage (Amps) 10.5
Color Black
Material Plastic/Stainless Steel
Condition New
Explosion Proof Yes
Install Options Indoor/Outdoor
Model TECO Vectorless Variable Frenquency Drive L510-203-H3-U
Amperage (Amps) 10.5
Phase 1
Product Dimensions (Inches) 5.67 x 4.65 x 5.8
Voltage (Volts) 230 VAC
Output Voltage (Volts) 240 VAC
Phases In/Out 3-3
Horsepower 3
Water Resistant/Hosedown Yes
