Carlo Gavazzi Ultrasonic Sensor, M18 Cylinder, 10-30 VDC, 50-400 mm Sensing, PNP NO/NC Output, UA18CAD04PKTI

Special Price $349.00 was $391.00
Carlo Gavazzi Ultrasonic Sensor UA18CAD04PKTI, 2M 4wire Cable, 400mm Max Sensing

15-30 VDC and 2x PNP NO/NC
Carlo Gavazzi Ultrasonic M18 UA18 sensor is a self-contained multi function diffuse ultrasonic sensor with a sensing range of 50 to 400mm. 2 switching PNP outputs - easIly set up for two different output modes and adjusted by teach-in - makes it ideal for level control tasks in a wide variety of vessels. A sturdy one-piece polyester housing provides the perfect packaging for the sophisticated microprocessor controlled and digitally filtered sensor electronics. Excellent EMC performance and precision are typical features of this sensor on true distance measurement.

PBT-Polyester housing

Sensing distance: 50 - 400 mm

Outputs: 0-10V and a digital PNP output, NO or NC

Setup: Normal switching or adjustable hysteresis

Power supply: 15 to 30 VDC

8° beam angle

Protection: Short-circuit, reverse polarity, overvoltage

Protection degree IP 67

2 Meter Cable, 4 wires

CE approved and cULus (UL508)

Carlo Gavazzi model UA18CAD04PKTI

Brand Carlo Gavazzi
MFR Part Number UA18CAD04PKTI
Application Industrial Automation
Color Gray
Material Polyester
Condition New
Explosion Proof Yes
Install Options Indoor/Outdoor
Model Gavazzi_Ultrasonic_Sensor UA18CAD04PKTI
Diameter (mm) 18
Sensing Distance (mm) 50-400
Sensor Output 0-10V / PNP
Phase 1
Product Dimensions (Inches) 3.1 x .71
Voltage (Volts) 15-30 VDC
Water Resistant/Hosedown Yes
